Lighting Assembly Machinery

This LED bulb assembly line completes the automated assembly processes for E14 bulb lamps, including automatic component insertion of light source boards, automatic lamp cup loading, automatic pressing, automatic wire bending, automatic wire cutting, automatic lamp cap component assembly, automatic gluing, automatic bulb shell mounting, automatic testing, and automatic defective product sorting.

Designed for A-series bulbs (A55/A60/A70, etc.), this fully automatic A-bulb production line integrates core processes including automatic wire stripping, wire insertion, lamp holder assembly, gluing, bulb shell mounting, testing and defective product sorting. It realizes batch production from components to finished products via an intelligent control system, and can be flexibly configured into fully automatic or semi-automatic versions according to enterprise production capacity requirements.

The GU10 spin riveting machine is a non-standard automated riveting device specially designed for the production of GU10 lamps, which is mainly used for spin riveting and fixing the pins (electrode pins) of the GU10 lamp cap and the lamp holder assembly.This GU10 Pin Spin Riveting Machine automatically completes the processes of pin feeding, spin riveting and blanking. The feeding method of the lamp cup can be selected as manual or automatic feeding according to requirements.It can be compatible with both glass and plastic lamp cups.

The automatic light source board insertion machine is advanced automated equipment designed for high-efficiency and high-precision insertion of electronic components onto LED light source boards and LED modules. This light source board insertion machine handles processes including automatic feeding of light source boards, insertion of safety resistors, wire insertion, electrolytic capacitor insertion, and automatic blanking. It is widely used in LED lighting manufacturing, including LED bulb light boards, panel lights, strip lights, linear lights, and customized LED modules.

Full-Automatic Insertion Production Line for Filament Lamps light source boards : Manually place the light source boards into the magazine → Automatic Light Source Board Loading → Automatic Component Feeding (Resistors/Wires) →Automatic  Insertion → Automatic Blanking. Offline and inline connection  modes are available for selection.

The GU10 automatic assembly line is a complete set of intelligent manufacturing equipment designed for the large-scale and automated production of GU10 lamps. This production line realizes automatic assembly processes,such as automatic gluing, automatic inner sleeve installation, automatic testing, automatic riveting, automatic lens gluing, and automatic lens installation. It can be matched with supporting equipment such as laser marking machines, aging test machines, and box packing machines to expand production process links and meet the customized production needs of different customers.

Synrit’s direct-lit panel light assembly line is a fully automatic intelligent light production line tailored for the 3C lighting and commercial lighting sectors. It enables integrated manufacturing of direct-lit panel lights, covering the entire process from core component loading to finished product inspection and unloading.   This panel light production line automatically completes all assembly procedures, including core processes such as glue dispensing, light source mounting, soldering and screw fastening. With a daily output of up to 5,000 units and a stable yield rate of over 99.5%, it helps enterprises achieve efficient and standardized mass production of panel lights.
